A Type Battery Cage For Layers Or H Frame Battery Cage For Layers: Complete Guide From Vanke China–Nigeria Branch

Time : Oct 20, 2025

Battery cage for layers is mainly divided into two systems: A type automatic layer cage and H frame automatic layer cage, each designed to meet different farm scales and automation requirements.

1. A Type Battery Cage For Layers

The structure is an inclined “A” type, commonly with 3–5 tiers, each group accommodating about 90–160 birds, suitable for small and medium farms (1,000–30,000 birds).

2. H Frame Battery Cage For Layers

The structure is a vertical “H” type frame, commonly with 6–16 tiers, each group holding 160–1080 birds, suitable for large-scale automatic farms (30,000–1,000,000 birds).

Common Specifications

System Type	Tiers	Doors	Bird Capacity (Per Group)	Single Cage Size (mm)	Overall Size (L×W×H/mm)	Suitable Farm Scale
A Type 3 Tiers 4 Doors	3	4	96 birds	450×350×380	1950×2100×1650	3,000–10,000 birds
A Type 5 Tiers 5 Doors	5	5	160 birds	450×450×410	1950×2200×2100	10,000–30,000 birds
H Type 6 Tiers 5 Doors	6	5	200 birds	450×450×410	1950×2300×2600	30,000–800,000 birds
H Type 8–16 Tiers	8–16	5	240+ birds	Customized size	1950×2500×3200–6000	50,000–1,000,000 birds

Note: overall size includes frame, aisle, manure, and egg collection space. customization is available based on shed height, ventilation, and layout.

Material And Anti-Corrosion Treatment

Material Type	Anti-Corrosion Method	Feature	Service Life
Q235 Low Carbon Steel	Electro galvanized	Cost-effective, moderate corrosion resistance	7–10 years
Q235 Low Carbon Steel	Hot-dip galvanized	Thick zinc layer, strong corrosion resistance	15–20 years
High-Strength Steel Wire	Zinc-aluminum alloy or PVC coating	Cest rust protection, smooth surface	Over 20 years

suggestion:
in humid or coastal areas, choose hot-dip galvanized or zinc-aluminum alloy materials;
check welding smoothness to prevent egg or foot damage;
regular cleaning and anti-rust maintenance extend cage lifespan.

Structure Description

A Type Automatic Layer Cage Structure Description

Structure Part	Material Composition	Function Description	Feature
Main Frame	Galvanized angle steel or square tube	Supports entire cage body	Stable and easy installation
Cage Mesh	Q235 steel wire galvanized	Holds layers, ensures ventilation	Smooth surface, protects feet
Bottom Slope	7–8° inclined design	Eggs roll automatically to egg tray	Reduces egg breakage
Egg Tray	Stainless steel or galvanized sheet	Collects eggs	Easy to clean
Feeding System	Manual trough or automatic feeder	Provides uniform feed	Supports automation
Drinking System	PVC pipe + nipple drinker	Supplies clean water	Water-saving and hygienic
Manure System	Scraper belt or manual cleaning	Removes waste	Semi-automatic optional
Ventilation Design	Layer gap design	Keeps airflow smooth	Ideal for naturally ventilated sheds

H Frame Automatic Layer Cage Structure Description

Structure Part	Material Composition	Function Description	Feature
Main Frame	Thick-walled galvanized square tube	Supports multi-tier structure	Strong bearing capacity
Cage Layout	High-strength welded mesh	Houses birds per layer	High density, space saving
Feeding System	Automatic feeder or spiral conveyor	Continuous and efficient feed supply	Uniform and fast feeding
Drinking System	Stainless water line + regulator	Balances pressure across layers	Automatic and efficient
Egg Collection System	Belt + elevator + collection table	Delivers eggs automatically	Reduces breakage
Manure Removal System	Full automatic belt	Centralized manure disposal	Keeps shed clean
Ventilation & Lighting	Automatic fans + LED control	Optimizes environment	Improves egg production
Environmental Control	Temperature, humidity, negative pressure	Regulates environment automatically	Suitable for closed large-scale houses

Selection Guidance

Battery cage for layers should be selected based on the farm’s size, management goal, and environmental condition.

For 5,000–10,000 birds, use a type automatic layer cage (cost-effective and easy maintenance).
For 30,000–1,000,000 birds, choose h frame automatic layer cage (high automation and density).
In humid or salty regions, use hot-dip galvanized or zinc-aluminum alloy materials.
For long-term operation and automatic control, h frame system is the best choice.
