With the continuous modernization of poultry farming, choosing the right battery cage for layer system has become the key to improving productivity and farm efficiency.

Vanke China–Nigeria Branch provides advanced A-type and H-type battery cage for layer solutions designed for different scales of poultry farms - From 100 birds/house to 100,000 birds/house.

Cage System Type, Farm Scale, And House Configuration

The following table shows the main differences among three types of battery cage for layer systems in automation level, suitable farm size, and layer range to help customers make better investment decisions.

System Type	Chicken House Size (Approx.)	Suitable Farm Type	Layer Range	Birds Per House	Automation Level	Main Features
Semi-Automatic A-Type Battery Cage For Layer	70m × 10m × 3.5m	Small and medium farms (10,000–30,000 birds)	2–4 layers	10,000–30,000	Automatic drinking + semi-automatic feeding (feed cart/trough)	Low cost, easy operation, ideal for start-up farms with manual labor.
Full Automatic A-Type Battery Cage For Layer	80m × 12m × 5m	Medium to large farms (30,000–60,000 birds)	3–5 layers	30,000–60,000	Automatic feeding + egg collection + manure removal	Stable structure, space-saving, high efficiency, best option for automation upgrading.
Full Automatic H-Type Battery Cage For Layer	90–100m × 14–16m × 8–10m	Large modern farms (50,000–1,000,000 birds)	6–16 layers	50,000–1,000,000	Automatic feeding + egg collection + manure cleaning + environment control	High density, saves space, full automation, ideal for industrial farming.

Structure And Material Specification Comparison

The table below compares the structure, materials, and durability of each battery cage for layer system to support engineering design and farm equipment planning.

Item	Parameter Data	Semi-Automatic A-Type	Full Automatic A-Type	Full Automatic H-Type
Cage Dimension (L×W×H)	—	1.9–2.2 × 2.0 × 1.8 m	2.0×2.2×1.8m	2.1×1.2×2.0m
Layer Range	2–4 / 3–5 / 4–16	2–4 layers	3–5 layers	6–16 layers
Capacity Per Unit (Birds)	90–640	90–160	120–320	240–640
Frame Material	Q235 / Q345 steel wire	Q235 electro-galvanized	Q235/Q345 hot-dip galvanized	Q345 hot-dip galvanized + stainless parts
Surface Coating Thickness	15–25μm (electro) / 80–100μm (hot-dip)	15–25μm	80μm	100μm
Drinking System	Nipple distance 35cm	Automatic nipple line	Automatic constant pressure system	Automatic pressure + water filtration
Manure Removal System	Belt speed 5–10 m/min	Manual or belt type	Automatic belt cleaning	Central automatic cleaning
Egg Collection	—	Manual	Automatic egg collector	Conveyor + elevator collection
House Height Required	≥3.5m / ≥5m / ≥6m	≥3.5m	≥5m	≥6m
Service Life	8–25 years	8–10 years	12–18 years	15–25 years

Purchasing And Construction Recommendations

House planning: A-type systems suit standard steel structure houses; H-type requires taller, stronger buildings.
Investment return: Semi-automatic A-type offers the lowest cost; full automatic A-type fits mid-size farms; H-type delivers the highest automation and performance.
Corrosion protection: Hot-dip galvanized or stainless steel is recommended in humid regions to extend battery cage for layer lifespan.
System scalability: Full automatic A-type is ideal for farms upgrading from manual to modern automatic production.
One-stop service: Vanke China–Nigeria Branch provides full project solutions — from design and equipment supply to installation and after-sales training for farms ranging from 10,000 to 1,000,000 layers.
