Popular Type Battery Cage For Layers For Sale From Vanke China–Nigeria Branch

Time : Oct 20, 2025

Vanke Machinery & Equipment Co., Ltd. provides high-quality battery cage for layers systems designed for modern poultry farms. Both H type and A type systems are widely used in egg production projects of 2,000–100,000 birds, offering durability, ventilation, and easy installation.

1. H type battery cage for layers
6–16 tier vertical design, suitable for large fully automatic farms with 30,000–100,000 birds per house.

2. A type battery cage for layers
3–8 tier inclined design, ideal for medium and small farms with about 30,000 birds per house.

System Type And Application Scale

This table helps customers choose the right system based on their farm scale and automation level, data for reference only.

Slide the table to view.

System Model	Suitable Capacity (Birds)	Tier Structure	Automation Configuration	Service Life
H type automatic layer cage	30,000–100,000+	H type 6–16 layers hot-dip galvanized steel	Automatic feeding, automatic drinking, automatic egg collection, automatic manure removal	≥20 years
A type automatic layer cage	10,000–30,000	A type 4–8 layers	Automatic feeding, automatic drinking, automatic manure removal	≥20 years
A type semi-automatic layer cage	2,000–10,000	A type 3–6 layers	Semi-automatic feeding, automatic drinking	≥20 years

Material And Structural Details

This table introduces the key materials and structures for better understanding of product durability and corrosion resistance, data for reference only.

Slide the table to view.

Component Name	Material Description	Process And Structural Features
Cage mesh	Q235 low-carbon steel wire (φ3.0–4.2mm)	Hot-dip galvanized ≥275g/m², mesh size 22×50mm / 25×50mm, tensile strength ≥400n/mm²
Front door	Galvanized steel wire (φ3.5mm)	Height 280–320mm, opening angle ≤110°, strength ≥350n/mm²
Bottom mesh	Q235 high-elastic wire (φ3.0mm)	Slope 7–8°, zinc layer ≥300g/m², load strength ≥450n/mm²
Support column	Hot-dip galvanized square tube (40×40mm / 50×50mm)	Thickness 1.5–2.0mm, zinc layer ≥80μm, vertical load ≥250kg
Beam and side bar	Q235 galvanized bent steel plate (1.5–2.0mm)	Punching precision ±0.2mm, connection strength ≥500n/mm²
Tier support frame	Galvanized channel or angle steel (2.0mm)	Welding strength ≥350n/mm², anti-corrosion life ≥15 years
Egg guard	PVC coated or galvanized edge	Thickness 1.0mm, arc 30°, impact strength ≥200n
Door latch	Galvanized carbon steel or stainless steel	Hardness ≥hrc28, 20,000 opening cycles, salt spray ≥720h
Support leg	Galvanized angle steel (2.0mm)	Adjustable ±20mm, load ≥500kg
Bolt	Galvanized high-strength bolt (grade 8.8)	Tensile ≥800mpa, m8–m12 standard
Anti-corrosion layer	Zinc or epoxy coating	Thickness 80–100μm, salt spray ≥720h

Chicken House Layout And Size Comparison

This table helps customers plan the chicken house layout for different breeding scales, data for reference only.

Slide the table to view.

House Capacity (Birds)	Cage Type	Tier	House Length (M)	House Width (M)	Floor Area (㎡)	Remark
10,000	A type automatic	4–6 layers	50–60	8–10	400–500	Medium open house
30,000	H type automatic	8–12 layers	70–80	12–14	800–1000	High-density closed house
50,000	H type automatic	12–16 layers	85–100	14–16	1100–1300	Large multi-tier system
100,000	H type automatic	14–16 layers	120–150	16–18	1600–2000	Super large integrated farm
